ALKINOOS
BUILT: 2019
CLASS: ABS
FLAG: LIBERIA
BUILDER: Shanghai Waigaoqiao Shipbuilding Co., Ltd.(SWS), China
VESSEL PARTICULARS
Type of vessel:
.A1, CPS-COT, Oil Carrier, ESP, AMS, ACCU, CSR, CPS with additional notations: BWE, BWT, CRC(I), IHM, Ice Class IA 11199 kw, NBLES, POT, RRDA, SPMA, TCM, UWILD, VEC-L
Summer deadweight:
109,896 MT
Summer draft:
14.68 m
Summer freeboard:
6536.000 mm
GRT / NRT:
62,508 / 33,679
LOA:
249.95 m
Beam:
44.06 m
Depth:
21.20 m
Keel to mast:
50.53 m
CARGO ARRANGEMENTS
Cargo / slop tanks:
6 CARGO TANKS (P & S) / SLOPS ( P & S)
Cargo capacity (98% ex slop tanks):
122,289.60
Slop tank capacity (98%):
SLOP P 2,567.49 - SLOP S 2,024.70
Cargo tank coating:
High Build Epoxy Coating
Heating arrangement:
Heating coils
SBT / IGS / COW:
SBT: 39,991 m3 / IGS: 10,500 M3/HR /COW: 28 Tank cleaning machines
Distance bow to mid-point manifold:
120.17 m
Distance main deck to center manifold:
2100 mm
Distance manifolds to ship's rail:
4600 mm
Cranes / SWL:
Hose Crane 15T / Prov. Crane 2T & 4T / ER Crane 4T
CARGO PUMPS
Cargo pump type:
Vertical, Centrifugal, steam turbine driven
Number of cargo pumps:
3
Capacity of cargo pumps:
2800 m3/h
PROPULSION
Main engine:
Doosan - Man B&W 6G60ME-C9.5 Tier II
Propeller type:
Aerofoil 4 Blade Keyless Solid type NI-AL-BR 1 set diameter x pitch: 7.500 x 5.415
Generators:
3 x 900 kW @ 900 rpm FO or MGO
Bow thruster:
No
